Sun Sparc Enterprise T5120

T5120
Sun Sparc Enterprise T5120

Processors | Main Memory | Standard Interfaces | Internal Mass Storage | Power Supplies
| Dimensions and Weight | Rack Mounting

Processors
top

Number of Processors: One UltraSPARC T2 multicore processor

CPUs :
1.2GHz 4-Core
1.2GHz 6-Core
1.2GHz 8-Core
1.4GHz 8-Core
1.6GHz 8-Core

Architecture: SPARC V9 architecture, ECC protected

Cache Memory: 4MB Level 2

Processor boards available:

541-2150 : Sun Microsystems 8-Core 1.2GHz System Board Assembly, RoHS:Y for T5120 & T5220 Server

541-2155: Sun Microsystems 8-Core 1.4GHz System Board Assembly, RoHS:Y for T5120 & T5220 Server

541-2156 : Sun Microsystems 4-Core 1.2GHz System Board Assembly, RoHS:Y for T5120 & T5220 Server

540-7765 : Sun Microsystems 1.2GHz 8-Core System Board Assembly, RoHS:Y

540-7766 : Sun Microsystems 1.4GHz 8-Core System Board Assembly , RoHS:Y

540-7768 : Sun Microsystems 1.2GHz 4-Core System Board Assembly, RoHS:Y

540-7784 : Sun Microsystems 1.6GHz 8-Core System Board Assembly, RoHS:Y
Main Memory
top

Total DIMM slots: 16

Capacity : 128GB (16 × 8GB)

DIMM type: FBDIMM

DIMM size: 1 GB, 2GB, 4GB or 8 GB DIMMs

Memory Upgrades available:

SESX2A1Z p/n 501-7952 : Sun Microsystems 2GB Memory Expansion (2 × 1GB DDR2-667/PC2-5300 2-Rank/1Gbit SDRAM), RoHS:Y for Netra T5220, T5440 SPARC Enterprise T5120, T5140, T5220, T5240 (2 x 371-2142)

SESX2B1Z p/n 501-7953 : Sun Microsystems 4GB Memory Expansion kit (2 × 2GB DDR2-667/PC2-5300 2-Rank/1Gbit SDRAM), RoHS:Y for Netra T5220, T5440, SPARC Enterprise T5120, T5140, T5220, T5240. (2 x 371-2143)

SESX2C1Z p/n 501-7954 : Sun Microsystems 8GB Memory Expansion (2 × 4GB DDR2-667/PC2-5300 2-Rank/1Gbit SDRAM), RoHS:Y for for Netra T5220, T5440, SPARC Enterprise T5120, T5140, T5220, T5240. (2 x 371-2145)

SESX2B2Z p/n 511-1161 : Sun Microsystems 4GB Memory Expansion (2 × 2GB) X-Option, RoHS:Y


SESX2D1Z p/n 511-1262 : Sun Microsystems 16GB Memory Expansion (2 × 8GB) X-Option, RoHS:Y for Sun SPARC[tm] Enterprise T5120 T5140, T5220, T5240, T5440


SESX2A2Z p/n 511-1264 : Sun Microsystems 16GB Memory Expansion (2 × 8GB) X-Option, RoHS:Y for Sun SPARC[tm] Enterprise T5120 Server
Standard Integrated Interfaces
top

Network : 4 × 10/100/1000 Mbps ports

Network Management : One dedicated 10/100Base-T RJ-45 port Ethernet port

Serial Management : One dedicated RJ-45 port

Serial : One DB-9 connector

SAS : One LSI Logic SAS1068E SAS/SATA Controller chip interfacing to a four lane PCI-Express port

USB: Front: 2 USB 2.0 Ports
Rear: 2 USB 2.0 Ports


X4237A p/n 375-3606 : Sun Microsystems Quad Data Rate (QDR) InfiniBand PCIe Low Profile Host Channel

X6000A p/n 375-3424 : Sun Microsystems PCI Express Sun Crypto Accelerator 6000

X1236A-Z p/n 375-3382 : Sun Microsystems Dual Port 10Gb/sec 4x PCI Express Infiniband Host Channel Adapter - Low Profile, RoHS:Y

SG-XPCIE2FC-EM4 p/n 375-3397: Sun 4 Gb Dual FC PCI-E Emulex Host Bus Adapter (RoHS).

SG-XPCIE2F-EM8-Z p/n 371-4306 : Suns 4 Gb Dual FC PCI-E Emulex Host Bus Adapter (RoHS).

SG-XPCIE2FC-QF4 p/n 375-3356 : Sun 4 Gb Dual FC PCI-E Host Bus Adapter (RoHS).

SG-XPCIE2FC-QF8-Z p/n 371-4325 : Sun 8Gb Dual FC Host Bus Adapter

SG-XPCIE1FC-EM4 p/n 375-3396 : Sun Microsystems 4 Gb Single FC PCI-E Emulex Host Bus Adapter (RoHS).

SG-XPCIEFCOE2-Q-SR p/n 375-3681 : Sun Dual 10-Gigabit Ethernet PCI Express


SG-XPCIEFCOE2-Q-TA p/n 375-3682 : Sun Dual 10-Gigabit Ethernet PCI Express

SG-XPCIE2SCSIU320Z p/n 375-3357 : Sun Microsystems PCI-E Daul Channel Ultra 320 LVD SCSI Adapter

SG-XPCIE8SAS-E-Z p/n 375-3487 : Sun PCI-Express 8-Port Host Adapter


SGXPCIESAS-R-EXT-Z p/n 375-3537 : Sun 8-Port SAS RAID External Host Bus Adapter

X7280A-2 p/n 371-0905 : Sun PCI Express Dual Gigabit Ethernet UTP

X4447A-Z p/n 501-7606 : Sun Microsystems PCI Express Quad Gigabit Ethernet UTP

X7281A-2 p/n 371-0904 : Sun Microsystems PCI Express Dual Gigabit Ethernet MMF

X1027A-Z p/n 501-7283: Sun PCI Express Dual 10-Gigabit Ethernet Fiber

X4447A-Z p/n 511-1422: Sun PCI Express Quad Gigabit Ethernet UTP

X5558A p/n 375-3301 : Sun 10Gb/sec XFP Optical Transceiver Short Range

X5560A-Z p/n 375-3495 : Sun 10 Gb/sec XFP Optical Transceiver Long Range

X7280A-2 p/n 371-0905 : Sun PCI Express Dual Gigabit Ethernet UTP

X7281A-2 p/n 371-0904 : Sun PCI Express Dual Gigabit Ethernet MMF
Internal Storage
top

Tape: None

Disks available

Disks: All PTO standard configurations ship with 4 disk backplanes and cannot be changed later.

ATO configurations provide a 4 disk or 8 disk backplane option as a selectable item.

The maximum disk capacity depends on which backplane is selected, and cannot be changed later.

Up to 8 73GB (10K or 15K RPM), 146GB 10K RPM, and 300GB, 10K RPM SAS 2.5 inch form factor disk drives

Solid State Drives : Up to 4 32GB solid state drives

SESX3A11Z p/n 540-7354 : Sun Microsystems 73.4GB 10000 RPM SAS disk drive with bracket for SPARC Enterprise T5120, SPARC Enterprise T5140, SPARC Enterprise T5220, SPARC Enterprise T5240

SESX3C11Z p/n 540-7355 : Sun Microsystems 146GB 10000 RPM SAS disk drive with bracket for SPARC Enterprise T5120, SPARC Enterprise T5140, SPARC Enterprise T5220, SPARC Enterprise T5240


SESX3A21Z p/n 540-7361 : Sun Microsystems 73.4GB 15000 RPM SAS disk drive with bracket, for Sun Blade 6000, Sun Blade T6320, Sun Blade X8450, Sun Fire X4140, Sun Fire X4150, Sun Fire X4240, Sun Fire X4250, Sun Fire X4440, Sun Fire X4450

SESX3G11Z p/n 540-7869 : Sun Microsystems 300GB 1000 RPM SAS disk drive with bracket, RoHS-6 compliant. For SPARC Enterprise T5120, SPARC Enterprise T5140, SPARC Enterprise T5220, SPARC Enterprise T5240

SESX3Y11Z p/n 540-7841 : Sun Microsystems 32GB Solid State Drive Assembly, SATA Interface, RoHS:Y


501-7699 : Sun Microsystems 4-Slot Disk Backplane, PATA DVD, RoHS:Y

501-7797 : Sun Microsystems 8-Slot Disk Backplane, PATA DVD, RoHS:Y

511-1282 : Sun Microsystems 4-Slot Disk Backplane, SATA DVD, RoHS:Y

511-1283 : Sun Microsystems 8-Slot Disk Backplane, SATA DVD, RoHS:Y


DVD-ROM: 1 slimline DVD-Writer/CD-Writer

SESX9DV2Z p/n 541-3493 : Sun Microsystems SATA DVD-Writer/CD-Writer - USB Board Assembly, RoHS:Y

SESX9DV1Z p/n 541-2110 : Sun Microsystems PATA DVD-Writer/CD-Writer - USB Board Assembly, RoHS:Y
Power Supplies
top

2 × 658 Watt, hot-swappable, N+1 redundant power supply units (PSU)

SECX9PS41Z p/n 300-2234 : Sun Microsystems T5120 720 Watt Power Supply

SECX9PS11Z p/n 300-2015 : Sun Microsystems T5120 Power Supply Unit

300-2186 : Sun Microsystems 660 Watt DC Input Power Supply, Type D218, RoHS:Y
Dimensions and Weights
top

Height : 44.4 mm (1.75 in.)

Width: 425.5 mm (16.75 in.)

Depth: 714.4 mm (28.1 in.)

Weight: 16.55 kg (36.5 lb.)

Rack mounting
top

Racks are as follows:
Sun Rack 900-36N
Sun Rack 900-38
Sun Rack 1000-38
Sun Rack 1000-42
Sun Fire Cabinet
StorEdge 72" Expansion Cabinet
19" racks that meet EIA-310-D, including M6, 10-32, and square holes

SESX9RK1Z p/n 371-2741 : Sun Microsystems Screw-Mount Slide Rail Rackmount Kit, 730mm, RoHS:Y

SESX9RK2Z p/n 371-2740 : Sun Microsystems Snap-In Slide Rail Rackmount Kit, 730mm, RoHS:Y
